長く続く信頼
スリットランプ
Haag-Streitのスリットランプは、卓越した性能と優れた耐久性により、世界中の眼科医の間で根強く支持されています。100,000台を超えるオリジナルのスリットランプが、現在も日々の診療で活躍しているのがその証です。
当社製品の比較
| Elara 900 | BQ 900 | BP 900 | BI 900 | BM 900 | |
|---|---|---|---|---|---|
| Microscope | |||||
| Galilean microscope | ● | ● | ● | − | − |
| Kepler microscope | − | − | − | ● | ● |
| Stereo angle 13° | ● | ● | ● | ● | ● |
| Stereo variator (stereo angle 4.5°) | − | ○ | − | − | − |
| Inclined eyepiece | ● | ○ | − | − | − |
| Yellow filter | ● | ○ | ○ | ● | − |
| Second observer tube | − | ○ | − | − | − |
| Beam splitter | ● | ○ | − | − | − |
| Magnification (Std. Eyepieces) | |||||
| 6.3 × | ● | ● | − | − | − |
| 10 × | ● | ● | ● | ● | ● |
| 16 × | ● | ● | ● | ● | ● |
| 25 × | ● | ● | ● | − | − |
| 40 × | ● | ● | − | − | − |
| Illumination | |||||
| LED | − | ● | ● | ● | ● |
| RGB-LED (P-Type) | ● | − | − | − | − |
| Presets | ● | − | − | − | − |
| Infrared (Availability may vary by region) | ● | − | − | − | − |
| Background | ● | ○ | ○ | ○ | − |
| Tilt | − | ● | ● | ● | ● |
| Defocusing | − | ● | ● | ● | ● |
| Short illumination mirror | − | ○ | ○ | ○ | ○ |
| Filter | |||||
| Gray | ● | ● | ● | ● | ● |
| Red-free | ● | ● | ● | ● | ● |
| Blue | ● | ● | ● | ● | ● |
| Slit | |||||
| Width (continuous) (mm / inch) | 0 - 25 mm / 0 - 0.98 inches | 0 - 14 mm / 0 - 0.55 inches | 0 - 14 mm / 0 - 0.55 inches | 0 - 14 mm / 0 - 0.55 inches | 0 - 8 mm / 0 - 0.315 inches |
| Length (continuous) (mm / inch) | 0 - 14 mm / 0 - 0.55 inches | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 8 mm / 0.039 - 0.315 inches |
| Test mark fixation star | − | ● | ● | ● | ● |
| Imaging | |||||
| Integrated imaging (Stereo optional) | ● | − | − | − | − |
| IM 910 | − | ○ | − | − | − |
| IM 600 | − | ○ | ○ | − | − |
| Imaging Set BI 900 | − | − | − | ○ | − |
| DSLR camera connector | − | − | − | − | − |
| Integrated flash (slit and background) | − | − | − | − | − |
| Control elements | |||||
| Mechanical | ● | ● | ● | ● | ● |
| Color touch display | ● | − | − | − | − |
| Tonometry | |||||
| AT 900 mod. BQ | − | ○ | ○ | − | − |
| AT 900 mod. R | ○ | − | − | ○ | ○ |
| AT 900 mod. T | − | ○ | ○ | ○ | ○ |
| Dimensions | |||||
| Weight (kg / lbs) | 15.2 kg / 33.51 lbs | 12.7 kg / 20.28 lbs | 12.3 kg / 27.11 lbs | 12 kg / 26.45 lbs | 11.4 kg / 25.13 lbs |
| Dimensions L x W x H (mm / inch) | 560 mm × 401 mm × 330 mm / 22 x 15.8 x 13 inches | 305 x 332 x 700 mm / 12 x 13 x 27.56 inches | 305 x 332 x 700 mm/ 12 x 13 x 27.56 inches | 310 x 332 x 700 mm / 12.2 x 13 x 27.56 inches | 290 x 332 xx 700 mm / 11.42 x 13 x 27.56 inches |
● product-comparison.table-info.default | ○ product-comparison.table-info.optional | − product-comparison.table-info.notAvailable | □ product-comparison.table-info.notRecomended
Confidence that lasts
